18.00-25 Port Tyre

14.00-24 18-00-25-port-tyre

14.00-24 18-00-25,18.00-33 port tyre

Tire Specification

--It is suitable for port equipment such as large-tonnage forklifts, stackers, front hoists, gantry cranes, etc.

--The carcass is solid, the bead is specially treated, the support capacity is strengthened, the heat generation is low, and the tread has a wide running surface and a block-shaped deepening pattern.

--Excellent grip, excellent braking performance and stability under heavy load and excellent operational safety.

--The tread has a high wear-resistant formula, good wear performance and longer tire life. It has good air tightness and reduces the number of air supply.

--The carcass adopts materials with low heat generation and good adhesion performance, which greatly reduces the probability of tire delamination. It can be refurbished several times to reduce the cost of tire use.



(SIZE)

(PR)

(TYPE)

(T.D)
(mm)

(Std. Rim)

(LOAD CAPACITY AT VARIOUS SPEED)
(S.W.)
(mm)

(O.D.)
(mm)
Inflation
Pressure

0km/h Creep 5km/h 10km/h 15km/h 20km/h 25km/h 30km/h

Static Creep 3mph 5mph 9mph 12mph 15mph 19mph
18.00-33 40 TL 69 13.00/2.5 1150kPa kg 35600 31670 28700 26700 25710 25120 24700 24500 509 1860
165lbs lbs 78480 69800 63270 58860 56660 55360 54450 54000
18.00-25 40 TL 68 13.00/2.5 1000kPa kg 30600 27200 24650 22950 22100 21590 21250 21080 528 1684
145psi lbs 67470 59980 54350 50610 48730 47610 46860 46480
